Arc Audio
Nighthawk 2 Channel Amplifier
Amplifier
The ARC Audio Nighthawk delivers high-output, low-distortion power without adding DSP complexity. Designed as a natural companion to ARC Audio DSP-equipped amplifiers such as Blackbird, it uses a matching chassis and industrial design for clean system integration. This fully bridgeable two-channel Class-D...
Overview & features
The ARC Audio Nighthawk delivers high-output, low-distortion power without adding DSP complexity. Designed as a natural companion to ARC Audio DSP-equipped amplifiers such as Blackbird, it uses a matching chassis and industrial design for clean system integration.
This fully bridgeable two-channel Class-D amplifier is rated for up to 800 watts at 4 ohms mono under CTA-2006. Balanced differential inputs, selectable stereo or mono operation and full-range performance from 10 Hz to 32 kHz make it suitable for subwoofers, midbass drivers and full-range component systems.
Features
- Fully bridgeable high-end Class-D two-channel amplifier
- Up to 800 watts bridged at 4 ohms mono, CTA-2006 compliant
- Balanced differential inputs
- Selectable stereo or mono configuration
- Full-range performance from 10 Hz to 32 kHz
- Compatible with ARC Audio high-current speaker connections
- Start-stop compliant operation down to 4.6 V
- Thermally stable from -4 F to 180 F
- Matching chassis and industrial design for ARC Audio DSP amplifier systems
- No onboard DSP
Power & channels
- Channels
- 2
- Amplifier class
- Class D
DSP processing & amplifier stage
- Frequency response
- 10 Hz-32 kHz
- Inputs
- Balanced differential
- Outputs
- Up to 800 W at 4 ohms mono (CTA-2006 compliant)
