ESX Audio

ESX Audio QE1000.1 1-Channel Class D Digital Amplifier

DSP Amplifier

£299.99
Available to order

The ESX QUANTUM QE1000.1 is a high-power mono Class D digital amplifier designed for demanding subwoofer systems, with variable filtering, phase control and a compact level remote. Key specifications 1 x 350/600/1000 Watts RMS @ 4/2/1 Ω Subsonic 10-40 Hz LPF 40-150...

At a glance SKU QE1000.1
Amplifier channels1 channel; 1 x 350 W RMS @ 4 Ω; 1 x 600 W RMS @ 2 Ω; 1 x 1000 W RMS @ 1 Ω
Amplifier classClass D; digital
Technical overview DSP platform and product features
Signal-to-noise ratio>81 dB
System roleIntegrated amplifier stage
Overview & features

The ESX QUANTUM QE1000.1 is a high-power mono Class D digital amplifier designed for demanding subwoofer systems, with variable filtering, phase control and a compact level remote.

Key specifications

  • 1 x 350/600/1000 Watts RMS @ 4/2/1 Ω
  • Subsonic 10-40 Hz
  • LPF 40-150 Hz
  • Bass Boost 0-18 dB
  • Phase Shift 0-180°
  • Dimensions 280 x 46 x 165 mm
  • Efficiency up to 92%

Manufacturer source: ESX product page
Manual: Owner's manual

Power & channels
Amplifier class
Class D; digital
Amplified channels
1 channel; 1 x 350 W RMS @ 4 Ω; 1 x 600 W RMS @ 2 Ω; 1 x 1000 W RMS @ 1 Ω
Technical overview
Frequency response
10-150 Hz (-3 dB)
Signal-to-noise ratio
>81 dB
Total harmonic distortion
<0.01%
Additional specifications
Low-pass filter
150 Hz
Bass boost
18 dB
Downloads
QE1000.1 manual QE1000.1 datasheet
