ESX Audio

ESX Vision 7ch DSP amp 5x100w + 2x200w @ 2ohm for subs with MBUX Harness

DSP Amplifier

£1,049.99
Available to order

Vehicle-specific package using the ESX Vision VE900.7SP platform with the correct Mercedes MBUX harness package scope. Package compatibility Vehicle scope: Mercedes Factory audio scope: Mercedes MBUX harness Package pricing source: ESX Trade 2026 explicit package row Confirm exact vehicle model, year and...

At a glance SKU VE900.7 Merc MBUX
Amplifier channels7 amplified speaker/subwoofer outputs (5 x 100 W + 2 x 200 W)
DSP channels48 DSP channels
Amplifier classClass D; 5 x 100 W RMS @ 4/3 Ω + 2 x 200 W RMS @ 2 Ω
Dimensions250 x 50 x 150 mm (L x H x W)
Technical overview DSP platform and product features
Signal-to-noise ratio106 dB A-weighted
DSP channels48 DSP channels
Sample rate96 kHz / Full HD Audio
DSP precision32-bit A/D and D/A
System roleIntegrated amplifier stage
Overview & features

Vehicle-specific package using the ESX Vision VE900.7SP platform with the correct Mercedes MBUX harness package scope.

Package compatibility

  • Vehicle scope: Mercedes
  • Factory audio scope: Mercedes MBUX harness
  • Package pricing source: ESX Trade 2026 explicit package row
  • Confirm exact vehicle model, year and factory audio system before installation.

Platform highlights

  • Class D 7-channel amplifier with integrated DSP
  • 5 x 100 watts RMS plus 2 x 200 watts RMS at 2 ohms for subwoofers
  • High-level input, RCA input and Bluetooth/app control support
  • Mercedes MBUX harness package scope
Power & channels
Amplifier class
Class D; 5 x 100 W RMS @ 4/3 Ω + 2 x 200 W RMS @ 2 Ω
Amplified channels
7 amplified speaker/subwoofer outputs (5 x 100 W + 2 x 200 W)
Technical overview
Frequency response
5-45,000 Hz
Signal-to-noise ratio
106 dB A-weighted
Total harmonic distortion
0.005% @ 1 W RMS; 0.003% @ 5 W RMS
DSP channels
48 DSP channels
Sample rate
96 kHz / Full HD Audio
Bit depth
32-bit A/D and D/A
Installation
Dimensions
250 x 50 x 150 mm (L x H x W)
Additional specifications
DSP chip / platform
Analog Devices ADAU1452; 32-bit, 294 MHz DSP
Power / voltage
7.5-17 V
Inputs / outputs
6 x balanced RCA; 6 x high-level speaker inputs; optical S/PDIF 96 kHz/24-bit; Bluetooth stereo; USB Mini-B; RJ45 remote; 5 x amplified speaker outputs; 2 x amplified speaker/subwoofer outputs; RCA subwoofer output
Bluetooth
Integrated Bluetooth 5.0 receiver with app control and audio streaming; antenna included
Downloads
ESX Vision 7ch DSP amp 5x100w + 2x200w @ 2ohm for subs with MBUX Harness manual ESX Vision 7ch DSP amp 5x100w + 2x200w @ 2ohm for subs with MBUX Harness datasheet
